Six ELS-SFPQ wet granulation spray guns from ≤1 to ≤45 kg/min convert between pressure and air atomization in-line — one gun family spans 1 L lab bowls to 800 L production.
Highlights
One gun covers small lab bowls to 800 L production bowls — convert atomization mode without changing hardware.
Lance design drains clean and mounts/dismounts without tools — faster batch changeover.
Ⅰ/ⅠA ≤1, Ⅱ/ⅡA ≤6, Ⅲ/ⅢA ≤45 kg/min — same geometry across scales.
Applications
- High-shear wet granulator binder dosing
- Fluid bed wet granulation
- Melt/wax spraying with heated lances
Product Images
Full Specifications
| Model | Max liquid | Note | Evidence |
|---|---|---|---|
| ELS-SFPQ Ⅰ | ≤1 kg/min | pressure/air convertible | Manufacturer spec |
| ELS-SFPQ ⅠA | ≤1 kg/min | streamlined body | Manufacturer spec |
| ELS-SFPQ Ⅱ | ≤6 kg/min | pressure/air convertible | Manufacturer spec |
| ELS-SFPQ ⅡA | ≤6 kg/min | streamlined body | Manufacturer spec |
| ELS-SFPQ Ⅲ | ≤45 kg/min | production bowls | Manufacturer spec |
| ELS-SFPQ ⅢA | ≤45 kg/min | production, streamlined | Manufacturer spec |
FAQ
Why does my wet granulation spray gun clog with HPMC binder solution?
HPMC solutions skin over as solvent evaporates at the nozzle tip. Anti-deposition gun bodies, tip flushing routines and quick-detach nozzles reduce clogging; bore size should be matched to viscosity and solid content.
Can the binder spray gun work with a peristaltic pump system?
Yes — the guns are designed for pump-fed closed-loop addition, with spray rate following the granulation torque curve for endpoint control.
Pressure atomization or air atomization for binders?
Combination is best: pressure atomization carries the liquid into the bed, air atomization breaks the sheets into fine droplets. The ELS-SFPQ series combines both in one gun.
